Product DescriptionCompany Info.
- Principle:
- Vacuum filtration
- Style:
- Vertical type
- Applicable object:
- Lubricating oil
- Model:
- TRZJD50Q
- Filter type:
- Fibre
- Performance:
- High efficiency filtration
- Rated flow:
- 0.36 m3/h
- Working pressure:
- 0.4 MPa
- Operating noise:
- 80 dB
- Inlet and outlet pipe diameter:
- 25 mm
- Deemulsification number:
- 15 min
- Cleanliness:
- 6-8 NAS
- Overall dimension:
- 000 mm
- Effective filtration area:
- 0.2 ㎡
- Machine power:
- 11 kw
- power supply:
- 380V 50HZ
Usage:
ZJD series products of Chongqing Tongrui filter equipment are specially designed to improve the cleanliness level of lubricating hydraulic oil required by hydraulic and lubricating equipment of construction machinery. And ZJD series products are commonly used in metallurgy, engineering machinery, automobile, mining, paper and other general industrial lubricating liquid filtration purification cases.
Solid, liquid, and dissolved contaminants inevitably present in lubricating fluids during transport, storage, or use can cause operational problems and increased maintenance for hydraulic, lubricant, and fuel systems on mobile equipment. If left unchecked, these pollutants can increase operating and maintenance costs, reduce equipment availability, and have a high cost impact on productivity. nbsp;
The high performance filtration products of Tonray brand oil purification equipment are specially designed to provide long-term equipment reliability and performance, improve the environment and reduce the cost of ownership.
Tongrui TR/ZJD series refrigeration oil vacuum filter can quickly remove moisture, gas and mechanical impurities from oil, flash remove light acids and light hydrocarbons, improve oil quality, restore the performance of refrigeration oil and compressor oil, and ensure the normal operation of refrigeration and compression systems.
Features:
● Strong ability to remove moisture, easy to remove trace moisture and gas from oil.
● Combination of coalescence separation and vacuum dehydration, the water separation device adopts excellent polymer membrane coalescence separation technology in the industry, which can quickly separate a large amount of water and micro water from lubricating oil with high water content.
● High filtration accuracy, improve oil performance.& nbsp;
● Automatic liquid level control, automatic constant temperature control, simple and reliable operation.& nbsp;
In case of some users who have higher requirements for the quality of refrigeration oil and compressor oil, the following configurations can be superimposed as ZJD-specialseries:
● The oil circulation part is made of stainless steel.
● Optional PLCcontrol or automatic touch screen control.
● Two-stage vacuum configuration can be used to increase the amount of extraction to shorten the oil treatment process and increase the post-treatment value of the water content in the oil.
Technical parameter table:
※ The appearance size and weight of the equipment of Tongrui TR/ZJD series refrigerator oil vacuum filter are for reference only, subject to the actual product.post-treatment index water content ppm 100 (according to oil conditions and customer requirements) gas content % ≤0.1(GB/T423) cleanliness NAS 6~8grades mechanical impurity content % not have emulsion breaking value Min ≤15min indicator name unit ZJD-6 ZJD-10 ZJD-20 ZJD-30 ZJD-50 ZJD-75 ZJD-100 ZJD-150 ZJD-200 flow L/H 360 600 1200 1800 3000 4500 6000 9000 12000 working vacuum Mpa -0.06~ -0.095 work stress Mpa ≤0.4 constant temperature control range ℃ 0~ 100 power supply 380V/50Hz(according to user requirements) working noise dB(A) ≤75 ≤78 ≤80 ≤82 electric heating power kW 9 15 30 30 45 60 96 120 135 total electric power kW 11 17 32 33 48 65 102 135 147 Inlet (outlet)diameter mm 15 25 25 25 32 42 50 50 60 installation (unit) weight Kg 350 450 550 600 750 850 1000 1200 1500 - ------------
Manufacturer:Chongqing Tongrui Filter Equipment Manufacturing Co., Ltd.(Brand: TR/Tongrui)
Chongqing Tongrui Oil Filter Company is an experienced manufacturer of oil filtration and purification equipment, producing and selling various lubricating oil filters, turbine oil filters, transformer oil filters and light fuel oil filters, as well as ordinary filter dispensers and waste oil regeneration filters. A wide range of products, we are independent export enterprises, technology and production strength, many times to CNOOC, Sinopec, Sany Technology, Futian Heavy Machinery, China Railway Bureau and other large enterprises at home and abroad project supply, is definitely your value of the letter resistant oil filter manufacturers.
Related accessories:Free delivery of a set of accessories (including hoop, glass tube, oil resistant rubber pad, PVC steel wire reinforced hose in and out of each 5 meters)
Freight description:manufacturers responsible for national freight, door-to-door delivery.
Supply cycle:Standard products are generally available in stock, even if there is no stock, the supply cycle is 5-7 working days
Packing:Bamboo Wooden Box
Quality guarantee:The warranty period of this product is 12 months after startup; Technical service: All (non-artificial) equipment problems within the warranty period are repaired free of charge by the manufacturer, and all non-artificial damaged accessories are free of charge (except consumables).
Tongrui TR/ZJD series refrigerator oil vacuum filter Other equipment Related accessories——
1. Oil filter element: (equipment size is different, filter element model is different, filter elements are stainless steel mat-type filter, can be cleaned repeatedly used
※ Cleaning method ※: Cleanthe filter element with clean cleaning oil (or gasoline) of the same type, and brush the filter element surface with a soft brush (the filter element surface can be removed for cleaning). After finishing, it is recommended to use an air compressor to aim at the filter element thread opening and blow air from the inside out. This helps to clean the filter element more cleanly.)
2, delivery configuration:ZJD series equipment delivery random distribution of a set of spare parts (including hoop, oil resistant rubber pad, sampling hose, PVCsteel wire reinforced hose in and out of each 5 meters).
Tips: Product pictures, prices and attributes for reference only! Details from electricity or Wangwang online consultation prevail, sincerely look forward to working with you!
ChongqingTongruiFilter Equipment Manufacturing Co., Ltd. has passed the international quality system certification, the company is committed to providing global customers with excellent cost-effective oil filter products. Chongqing Tongrui Filter Equipment Manufacturing Co., Ltd. has many years of experience in producing various oil filter equipment, is the old filter production manufacturers. The company has senior engineers and design researchers, can be tailored according to the different requirements of buyers and its appropriate models, to optimize the processing effect. Choosing us is believing in yourself!
